Impostazioni LaserGRBL per Incisione

Materials LU2-2 (≤2.1W) LU2-4-SF/LF (=5W) LU2-10A (=10W) LU3-20A/B (=20W) LU3-40A (=40W) LR4-2B (=2W)
MDF 3000mm/min, M4,
S700, 15Lines/mm		 10000mm/min, M4,
S1000, 15Lines/mm		 20000mm/min, M4,
S1000, 10Lines/mm		 20000mm/min, M4,
S400, 8Lines/mm		 20000mm/min, M4,
S550, 8Lines/mm		 ×
Plywood 3000mm/min, M4,
S700, 15Lines/mm		 10000mm/min, M4,
S1000, 15Lines/mm		 15000mm/min, M4,
S1000, 10Lines/mm		 20000mm/min, M4,
S800, 8Lines/mm		 20000mm/min, M4,
S800, 8Lines/mm		 ×
Pine 3000mm/min, M4,
S700, 15Lines/mm		 10000mm/min, M4,
S1000, 15Lines/mm		 20000mm/min, M4,
S1000, 15Lines/mm		 20000mm/min, M4,
S1000, 8Lines/mm		 20000mm/min, M4,
S700, 8Lines/mm		 ×
Paulownia 3000mm/min, M4,
S700, 15Lines/mm		 10000mm/min, M4,
S1000, 15Lines/mm		 20000mm/min, M4,
S700, 10Lines/mm		 20000mm/min, M4,
S400, 8Lines/mm		 20000mm/min, M4,
S700, 8Lines/mm		 ×
Paperboard
(Cardboard Box)		 3000mm/min, M4,
S1000, 12Lines/mm		 9000mm/min, M4,
S1000, 15Lines/mm		 20000mm/min, M4,
S700, 10Lines/mm		 20000mm/min, M4,
S350, 8Lines/mm		 20000mm/min, M4,
S600, 8Lines/mm		 ×
A4 Paper
(Not White)		 3000mm/min, M4,
S600, 12Lines/mm		 9000mm/min, M4,
S1000, 15Lines/mm		 3000mm/min, M4,
S150, 10Lines/mm		 20000mm/min, M4,
S350, 8Lines/mm		 20000mm/min, M4,
S400, 8Lines/mm		 ×
Kraft Paper 250g 2000mm/min, M4,
S100, 12Lines/mm		 9000mm/min, M4,
S1000, 15Lines/mm		 20000mm/min, M4,
S600, 10Lines/mm		 20000mm/min, M4,
S350, 8Lines/mm		 20000mm/min, M4,
S420, 8Lines/mm		 ×
Leather 3000mm/min, M4,
S1000, 15Lines/mm		 10000mm/min, M4,
S1000, 15Lines/mm		 20000mm/min, M4,
S600, 10Lines/mm		 20000mm/min, M4,
S300, 8Lines/mm		 20000mm/min, M4,
S400, 8Lines/mm		 1000mm/min, M4,
S1000, 15Lines/mm
Black Acrylic 2000mm/min, M4,
S1000, 15Lines/mm		 10000mm/min, M4,
S1000, 15Lines/mm		 20000mm/min, M4,
S1000, 10Lines/mm		 20000mm/min, M4,
S1000, 8Lines/mm		 20000mm/min, M4,
S800, 8Lines/mm		 4000mm/min, M4,
S1000, 15Lines/mm
Cobblestone × 1000mm/min, M4,
S1000, 15Lines/mm		 1000mm/min, M4,
S1000, 10Lines/mm		 2000mm/min, M4,
S1000, 8Lines/mm		 3000mm/min, M4,
S1000, 8Lines/mm		 ×
Ceramics × 1000mm/min, M4,
S1000, 15Lines/mm		 5000mm/min, M4,
S1000, 20Lines/mm		 10000mm/min, M4,
S1000, 15Lines/mm		 15000mm/min, M4,
S1000, 15Lines/mm		 ×

M3=Cutting Mode, M4=Engraving Mode, Conversion Tool: Line to Line Tracing (S=Strength, 1000=100%)
For more LaserGRBL engraving settings, please download LaserGRBL Settings PDF Document Below.

Impostazioni LaserGRBL per il taglio

Materials (Thickness) LU2-2 (≤2.1W) LU2-4-SF/LF (=5W) LU2-10A (=10W) LU3-20A/B (=20W) LU3-40A (=40W) LR2-4B (=2W)
♦ MDF
3mm 		× 200mm/min, M3, S1000
Perform Multiple Passes: 4		 250mm/min, M3, S1000
Perform Multiple Passes: 2		 400mm/min, M3, S1000
Perform Multiple Passes: 2		 800mm/min, M3, S1000
Perform Multiple Passes: 1		 ×
5mm × 200mm/min, M3, S1000
Perform Multiple Passes: 10		 250mm/min, M3, S1000
Perform Multiple Passes: 3		 600mm/min, M3, S1000
Perform Multiple Passes: 3		 600mm/min, M3, S1000
Perform Multiple Passes: 1		 ×
♦ Plywood
1.6mm		 × 300mm/min, M3, S1000
Perform Multiple Passes: 1		 500mm/min, M3, S1000
Perform Multiple Passes: 1		 800mm/min, M3, S1000
Perform Multiple Passes: 1		 1600mm/min, M3, S1000
Perform Multiple Passes: 1		 ×
2.8mm × 300mm/min, M3, S1000
Perform Multiple Passes: 1		 300mm/min, M3, S1000
Perform Multiple Passes: 1		 500mm/min, M3, S1000
Perform Multiple Passes: 1		 1100mm/min, M3, S1000
Perform Multiple Passes: 1		 ×
5mm × 100mm/min, M3, S1000
Perform Multiple Passes: 1		 350mm/min, M3, S1000
Perform Multiple Passes: 3		 350mm/min, M3, S1000
Perform Multiple Passes: 1		 700mm/min, M3, S1000
Perform Multiple Passes: 1		 ×
8mm × × 200mm/min, M3, S1000
Perform Multiple Passes: 3		 200mm/min, M3, S1000
Perform Multiple Passes: 1		 400mm/min, M3, S1000
Perform Multiple Passes: 1		 ×
10mm × × 100mm/min, M3, S1000
Perform Multiple Passes: 5		 250mm/min, M3, S1000
Perform Multiple Passes: 2		 250mm/min, M3, S1000
Perform Multiple Passes: 1		 ×
15mm × × × 200mm/min, M3, S1000
Perform Multiple Passes: 2		 200mm/min, M3, S1000
Perform Multiple Passes: 1		 ×
♦ Pine
3mm		 × 100mm/min, M3, S1000
Perform Multiple Passes: 1		 300mm/min, M3, S1000
Perform Multiple Passes: 1		 500mm/min, M3, S1000
Perform Multiple Passes: 1		 700mm/min, M3, S1000
Perform Multiple Passes: 1		 ×
5mm × 100mm/min, M3, S1000
Perform Multiple Passes: 1		 250mm/min, M3, S1000
Perform Multiple Passes: 1		 350mm/min, M3, S1000
Perform Multiple Passes: 1		 500mm/min, M3, S1000
Perform Multiple Passes: 1		 ×
8mm × 100mm/min, M3, S1000
Perform Multiple Passes: 3		 100mm/min, M3, S1000
Perform Multiple Passes: 1		 200mm/min, M3, S1000
Perform Multiple Passes: 1		 300mm/min, M3, S1000
Perform Multiple Passes: 1		 ×

M3=Cutting Mode, M4=Engraving Mode, Conversion Tool: Voctorize (S=Strength, 1000=100%)
For more LaserGRBL cutting settings, please download LaserGRBL Settings PDF Document Below.

Inizia a creare con Ortur!

Scarica il PDF delle impostazioni di LaserGRBLScarica il software LaserGRBL
  • Si prega di notare che i risultati di incisione e taglio possono variare anche sullo stesso materiale a seconda della sua finitura, colore e spessore.
  • Per ottenere prestazioni ottimali, regolare attentamente la velocità, le impostazioni di potenza e la lunghezza focale—assicurandosi che il punto focale sia il più piccolo e preciso possibile. Alcuni materiali come lastre metalliche lucide, superfici trasparenti o riflettenti e alcuni materiali bianchi o permeabili alla luce non possono essere incisi o tagliati direttamente; in questi casi, è necessario utilizzare un pennarello nero per creare una superficie di incisione.
  • Supervisionare sempre il laser durante il funzionamento per prevenire rischi di incendio e tenere un estintore nelle vicinanze per sicurezza. Per indicazioni dettagliate, si prega di fare riferimento ai manuali utente e ai tutorial ufficiali di Ortur.
